Application:
Used for manufacturing superheated pipelines, the steam pipe, boiling water tube, flue tube, small flue tube, etc.of low, mediam pressure boiler, the general industry boiler
High pressure boiler tubes are used in high temperature and high pressure conditions. Steel tubes are subject to oxidation and corrosion under the action of high temperature flue gas and water vapor. The steel tube is required to have high lasting strength, high oxidation resistance corrosion performance and good stability.
Application:
Used for manufacturing
superheated pipelines, the steam pipe, boiling water tube, flue tube, small
flue tube, etc.of low, mediam pressure boiler, the general industry boiler
|
Specifications |
|
|
Out Diameter |
16.0mm-219mm |
|
Wall Thickness |
2.0mm-4.0mm |
|
Length |
3.0m-18m |
|
Delivery status |
annealed, normalized, normalized + tempered and other heat treatment states |
|
Surface treatment |
oil dipping, painting, passivation, phosphating, shot blasting, etc. |
|
DIN17175 |
Its used for the pipelines of boiler industry. |
|
GB5310 |
For manufacture heating-pipelines, containers,
coal-saving devices, superheaters and reheaters of high pressure
boilers(P>9.8Mpa, 450℃ |
|
GB3087 |
For manufacture heating-pipelines, containers, steaming pipelines of low or medium pressure boilers(P≤5.88Mpa, T≤450℃) |
|
ASME SA-106 |
For manufacture wall panel, economizer, reheater, superheater, and steam pipeline of boilers. |
|
ASTM A192 |
Its used for high pressur, min wall thickness seamless carbon steel boiler and superheater tube. |
|
EN10216-1/2 |
It is applicable to manufacture pipelines, vessel, equipment, pipe fittings and steel structure in high pressure condition. |
|
Standard |
Grade |
Chemical composition(%) |
|
|
||||
|
C |
Si |
Mn |
P |
S |
Cr |
Mo |
||
|
DIN17175 |
St35.8 |
≤0.17 |
0.10-0.35 |
0.40-0.80 |
≤0.030 |
≤0.030 |
- |
- |
|
St45.8 |
≤0.21 |
0.10-0.35 |
0.40-1.20 |
≤0.030 |
≤0.030 |
- |
- |
|
|
15Mo3 |
0.12-0.20 |
0.10-0.35 |
0.40-0.80 |
≤0.030 |
≤0.030 |
- |
0.25-0.35 |
|
|
13CrMo44 |
0.10-0.18 |
0.10-0.35 |
0.40-0.70 |
≤0.030 |
≤0.030 |
0.70-1.10 |
0.45-0.65 |
|
|
10CrMo910 |
0.08-0.15 |
≤0.50 |
0.40-0.70 |
≤0.030 |
≤0.030 |
2.00-2.50 |
0.90-1.20 |
|
|
GB5310 |
20G |
0.17-0.24 |
0.17-0.37 |
0.35-0.65 |
≤0.030 |
≤0.030 |
- |
- |
|
20MnG |
0.17-0.24 |
0.17-0.37 |
0.70-1.00 |
≤0.030 |
≤0.030 |
- |
- |
|
|
15MoG |
0.12-0.20 |
0.17-0.37 |
0.40-0.80 |
≤0.030 |
≤0.030 |
- |
0.25-0.35 |
|
|
12Cr2MoG |
0.08-0.15 |
≤0.50 |
0.40-0.70 |
≤0.030 |
≤0.030 |
2.00-2.50 |
0.90-1.20 |
|
|
GB3087 |
10 |
0.07-0.14 |
0.17-0.37 |
0.35-0.65 |
≤0.035 |
≤0.035 |
≤025 |
- |
|
20 |
0.17-0.24 |
0.17-0.37 |
0.35-0.65 |
≤0.035 |
≤0.035 |
≤025 |
- |
|
|
ASME SA-106 |
106B |
≤0.30 |
≥0.10 |
0.29-1.06 |
≤0.025 |
≤0.020 |
- |
- |
|
106C |
≤0.35 |
≥0.10 |
0.29-1.06 |
≤0.025 |
≤0.020 |
- |
- |
|
|
ASTM A192 |
A192 |
0.06-0.08 |
≤0.25 |
0.27-0.63 |
≤0.035 |
≤0.035 |
- |
- |
|
EN10216-1 |
P195TR1 |
≤0.13 |
≤0.35 |
≤0.70 |
≤0.025 |
≤0.020 |
≤0.30 |
≤0.08 |
|
P235TR1 |
≤0.16 |
≤0.35 |
≤1.20 |
≤0.025 |
≤0.020 |
≤0.30 |
≤0.08 |
|
|
P265TR1 |
≤0.20 |
≤0.40 |
≤1.40 |
≤0.025 |
≤0.020 |
≤0.30 |
≤0.08 |
|
|
EN10216-2 |
P195GH |
≤0.13 |
≤0.35 |
≤0.70 |
≤0.025 |
≤0.020 |
≤0.30 |
≤0.08 |
|
P235GH |
≤0.16 |
≤0.35 |
≤1.20 |
≤0.025 |
≤0.020 |
≤0.30 |
≤0.08 |
|
|
P265GH |
≤0.20 |
≤0.40 |
≤1.40 |
≤0.025 |
≤0.020 |
≤0.30 |
≤0.08 |
|
|
Standard |
Grade |
Mechanical properties |
||
|
Tensile Strength (Mpa) |
Yield Strength (Mpa) |
Elongation (%) |
||
|
DIN17175 |
St35.8 |
360-480 |
≥235 |
≥25 |
|
St45.8 |
410-530 |
≥255 |
≥21 |
|
|
15Mo3 |
450-600 |
≥270 |
≥20 |
|
|
13CrMo44 |
440-590 |
≥290 |
≥20 |
|
|
10CrMo910 |
450-600 |
≥280 |
≥18 |
|
|
GB5310 |
20G |
≥415 |
≥245 |
≥24 |
|
20MnG |
410-550 |
≥240 |
≥22 |
|
|
15MoG |
450-600 |
≥270 |
≥22 |
|
|
12Cr2MoG |
450-600 |
≥280 |
≥20 |
|
|
GB3087 |
10 |
335-475 |
≥195 |
≥24 |
|
20 |
410-550 |
≥245 |
≥20 |
|
|
ASME SA-106 |
106B |
≥415 |
≥240 |
- |
|
106C |
≥485 |
≥275 |
- |
|
|
ASTM A192 |
A192 |
≥325 |
≥180 |
≥35 |
|
EN10216-1 |
P195TR1 |
320-440 |
≥195 |
≥27 |
|
P235TR1 |
360-500 |
≥235 |
≥25 |
|
|
P265TR1 |
410-570 |
≥265 |
≥21 |
|
|
EN10216-2 |
P195GH |
320-440 |
≥195 |
≥27 |
|
P235GH |
360-500 |
≥235 |
≥25 |
|
|
P265GH |
410-570 |
≥265 |
≥23 |
|
